Voicemeeter SAMMI

This SAMMI extension is bundled with a lightweight node express server application that is used to communicate with the Voicemeeter DLL.

--------------------------------

Before Use

--------------------------------

The Zip file must be extracted to your SAMMI folder so that it has the same file structure \extensions\poetry\Voicemeeter

The server will run on SAMMI start. Ensure your Voicemeeter program is running and then restart SAMMI after installing the sef.

--------------------------------

Small note: On server connect in the bridge, the labels for the strips and busses are requested and the drop downs in the commands are updated accordingly. If you change a label and want to see it in SAMMI, you can reload the bridge.

--------------------------------

Voicemeeter Get Strip Properties

--------------------------------

This command allows you to get the value of a property from the Strip (Left Side Inputs) The list below are all the available properties.

Note that standard Voicemeeter has 3 strips and 2 busses, Banana has 5 and Potato has 8.

Depending on your version, you won't see unavailable A or B values in the drop down list.

*   Mono

*   Mute

*   Solo

*   MC

*   Gain

*   Pan_x

*   Pan_y

*   Color_x

*   Color_y

*   fx_x

*   fx_y

*   Audibility

*   Comp

*   Gate

*   EqGain1 (High)

*   EqGain2 (Med)

*   EqGain3 (Bass)

*   FadeTo

*   A1

*   A2

*   A3

*   A4

*   A5

*   B1

*   B2

*   B3

--------------------------------

Voicemeeter Get Bus Properties

------------------------------

This command allows you to get the value of a property from the Bus (Right Side Outputs) The list below are all the available properties.

*   Mono

*   Mute

*   EQ

*   Gain

*   NormalMode

*   AmixMode

*   BmixMode

*   RepeatMode

*   CompositeMode

*   FadeTo

--------------------------------

Voicemeeter Set Strip Properties

--------------------------------

This command allows you to set the value of a property from the Strip (Left Side Inputs)

The list below are all the available properties.

Property	Value Range	Remark
Mono	0 (off), 1 (mono)	Mono Button
Mute	0 (off), 1 (on)	Mute Button
Solo	0 (off), 1 (on)	Solo Button
MC	0 (off), 1 (on)	Mute Center Button
Gain	-60 to +12 dB	Gain Slider
Pan_x	-0.5 to 0.5
Pan_y	-0 to 1.0	-0.5 to 0.5 for 5.1 pan pot
Color_x	-0.5 to 0.5	Physical Strip Only
Color_y	-0 to 1.0	Physical Strip Only
fx_x	-0.5 to 0.5	Physical Strip Only
fx_y	-0 to 1.0	Physical Strip Only
Audibility	0 to 10	Voicemeeter 1 only
Comp	0 to 10	Compressor Knob
Gate	0 to 10	Gate Knob
EqGain1	-12 to +12dB	Virtual Strip Only (High)
EqGain2	-12 to +12dB	Virtual Strip Only (Med)
EqGain3	-12 to +12dB	Virtual Strip Only (Bass)
FadeTo	String	(dBTarget, msTime)
A1-5	0(off), 1(on)	Out Bus Assignation
B1-3	0(off), 1(on)	Out Bus Assignation

--------------------------------

Voicemeeter Set Bus Properties

--------------------------------

This command allows you to set the value of a property from the Bus (Right Side Outputs)

The list below are all the available properties.

Property	Value Range	Remark
Mono	0 (off), 1 (mono), 2 (stereo reverse)	Mono Button
Mute	0 (off), 1 (on)	Mute Button
EQ	0 (off), 1 (on)	EQ Button
Gain	-60 to +12 dB	Gain Slider
NormalMode	0 (off), 1 (on)	BUS Mode
AmixMode	0 (off), 1 (on)	BUS Mode
BmixMode	0 (off), 1 (on)	BUS Mode
RepeatMode	0 (off), 1 (on)	BUS Mode
CompositeMode	0 (off), 1 (on)	BUS Mode
FadeTo	String	(dbTarget, msTime)
